XG 135 HD - 2010-2015 - 2T0410373/F10 - Castel Garden Ride On Mower Assembly Parts Diagram

Part No. xg_135_hd_2t0410373_f10_assembly_parts-group
XG 135 HD - 2010-2015 - 2T0410373/F10 - Castel Garden Ride On Mower Assembly Parts Diagram
XG 135 HD - 2010-2015 - 2T0410373/F10 - Castel Garden Ride On Mower Assembly Parts Diagram

Description

Castel Garden XG 135 HD Parts Diagram

Product Name - XG 135 HD

Model Year - 2010-2015

Model Type - NJX 92 Hydro

Art.N - 2T0410373/F10

Engine Model - Honda GXV 390

Ref. Img. Part No. Details
  1 Gasket. Ex. Pipe
Gasket. Ex. Pipe
HP18382-ZE9-800
Available to backorder
Gasket. Ex. Pipe
£14.50 £12.08

  10 Mark. Operator Caution (French) (Made In
Mark. Operator Caution (French) (Made In
HP87516-Z4H-801
Available to backorder
Mark. Operator Caution (French) (Made In
£12.48 £10.40

  10 Mark. Operator Caution (English) (Made I
Mark. Operator Caution (English) (Made I
HP87516-Z4H-010
Available to backorder
Mark. Operator Caution (English) (Made I
£3.94 £3.28

  14 Rectifier Assy. Regulator
Rectifier Assy. Regulator
HP31750-Z0A-821
Available to backorder
Rectifier Assy. Regulator
£177.24 £147.70

  15 Pump Assy. Fuel
Pump Assy. Fuel
HP16700-ZL8-013
Available to backorder
Pump Assy. Fuel
£60.48 £50.40


Description

Castel Garden XG 135 HD Parts Diagram

Product Name - XG 135 HD

Model Year - 2010-2015

Model Type - NJX 92 Hydro

Art.N - 2T0410373/F10

Engine Model - Honda GXV 390
