Viking MB650.1 VM - Frame, Height Adjustment - Parts Diagram

Name: Viking MB650.1 VM - Frame, Height Adjustment - Parts Diagram
SKU: mb650_1_vm_frame_height_adjustment-group
Price: 0.29 GBP
Availability: InStock

Part No. mb650_1_vm_frame_height_adjustment-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Viking MB650.1 VM - Frame, Height Adjustment - Parts Diagram

Description

Viking MB650.1 VM - Frame, Height Adjustment - Parts Diagram

	Part No.	Details
1	ST6375 760 4215 Available to backorder	Bracket right	£58.03 £48.36
2	ST9212 260 0900 In stock	Hexagon nut M6	£0.48 £0.40
5	ST9008 318 1280 Available to backorder	Hexagon head screw M6x16	£0.91 £0.76
7	ST6375 763 4501 Available to backorder	Strud	£60.31 £50.26
9	ST6375 760 4210 Available to backorder	Bracket left	£60.31 £50.26
10	ST6375 703 5111 Available to backorder	Tension spring	£2.15 £1.79
11	ST6375 708 8400 Available to backorder	Screw M4x20	£1.72 £1.43
12	ST6375 780 3193 Available to backorder	Notched quadrant (Contains 11+35)	£15.80 £13.17
13	ST6360 703 8800 Available to backorder	Translation lever	£50.20 £41.83
14	ST6375 763 2000 In stock	Pointer	£1.72 £1.43
15	ST9039 488 1502 Available to backorder	Self-tapping screw M8x14	£0.91 £0.76
16	ST9460 624 0400 In stock	E-clip 4	£0.53 £0.44
17	ST6375 703 5101 Available to backorder	Tension spring	£18.34 £15.28
18	ST6360 706 3400 Available to backorder	Cover	£4.78 £3.98
20	ST6375 760 1800 In stock	Rotary handle assy.	£11.08 £9.23
21	ST9307 021 0180 Available to backorder	Washer 84	£0.35 £0.29
22	ST6375 703 1700 Available to backorder	Rod	£34.60 £28.83
23	ST9104 007 4270 In stock	Self-tapping screw P5x16	£0.95 £0.79
24	ST6360 780 2091 Available to backorder	Cover assy. (Contains 25)	£23.32 £19.43
25	ST6375 701 3500 Available to backorder	Inspection glass	£1.14 £0.95
26	ST9039 488 0974 In stock	Self-tapping screw M5x12	£0.79 £0.66
27	ST9241 288 1980 Available to backorder	Cap nut M8	£0.79 £0.66
28	ST9070 010 1050 Available to backorder	Screw TT-M5x28	£1.03 £0.86
30	ST6375 703 6601 Available to backorder	Knob	£17.98 £14.98
31	ST6375 706 0701 Available to backorder	Cover	£51.20 £42.67
32	ST6375 703 5120 Available to backorder	Tension spring	£5.81 £4.84
33	ST6375 700 2710 Available to backorder	Flap assy. (Contains 34+39)	£49.22 £41.02
34	ST6375 706 6700 Available to backorder	Handle molding	£14.00 £11.67
35	ST6375 763 3020 Available to backorder	Bearing bushing	£5.36 £4.47
39	ST0000 967 3679 Available to backorder	Warning note	£2.15 £1.79
40	ST9039 488 1230 Available to backorder	Self-tapping screw M6x8	£0.77 £0.64
40	ST9039 488 1266 In stock	Self-tapping screw M6x12	£0.79 £0.66
