TWINCLIP 50 S H - 2017 - 294512038/S17 - Stiga Rotary Mower Carburettor Diagram

Name: TWINCLIP 50 S H - 2017 - 294512038/S17 - Stiga Rotary Mower Carburettor Diagram
SKU: twinclip_50_s_h_294512038_s17_carburettor-group
Price: 2.38 GBP
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

TWINCLIP 50 S H - 2017 - 294512038/S17 - Stiga Rotary Mower Carburettor Diagram

Description

Stiga TWINCLIP 50 S H Parts Diagram

Product Name - TWINCLIP 50 S H

Model Year - 2017

Model Type - MP2 504 S

Art.N - 294512038/S17

Engine Model - GCV 160 OHC Autochoke

Be the first to review this product

0 product questions

	Part No.	Details
2	MO118551931/0 Available to backorder	Float Set	£39.29 £32.74
3	MO118551932/0 Available to backorder	Chamber Set. Float	£62.16 £51.80
5	MO118551937/0 Available to backorder	Screw Set	£9.84 £8.20
7	HP16100-Z8B-871 Available to backorder	Carburetor Assy. (Bb75G A)	£99.24 £82.70
7	HP16100-Z8B-901 Available to backorder	Carburetor Assy. (Bb76A A)	£119.88 £99.90
7	HP16100-Z0L-N21 Available to backorder	Carburetor Assy. (Bb76F A)	£114.72 £95.60
11	HP16212-ZL8-000 In stock	Packing. Insulator	£2.86 £2.38
26	HP19651-Z0L-000 In stock	Guide. Air	£3.91 £3.26
28	MO118552010/0 Available to backorder	Control Assy. Choke	£88.37 £73.64
28	MO118552011/0 Available to backorder	Control Assy. Choke	£88.37 £73.64
31	MO118552014/0 In stock	Thermowax Assy.	£39.01 £32.51
33	HP16212-Z8B-900 Available to backorder	Packing. Insulator	£11.72 £9.77
