TORNADO 2098 AP - 2018-2020 - 2T0510481/AP18 - Stiga Ride On Mower Cutting Plate Diagram

Description

Stiga TORNADO 2098 AP Parts Diagram

Product Name - TORNADO 2098 AP

Model Year - 2018-2020

Model Type - SDS 98

Art.N - 2T0510481/AP18

Engine Model -

	Part No.	Details
1	MO382564209/4 In stock	Cutting Plate Grey Grey From S.N DD316744	£366.02 £305.02
2	MO325033086/0 In stock	Water Hose Connection	£1.55 £1.29
3	MO119035000/0 Available to backorder	Or Ring	£5.06 £4.22
4	MO382207204/1 In stock	Flange Assy	£102.06 £85.05
5	MO125020804/0 In stock	Blade Shaft	£35.20 £29.33
6	MO119216047/0 In stock	Bearing	£15.78 £13.15
7	MO325160501/1 Available to backorder	Dust Cover Disc From S.N 19CA3RON000144	£1.55 £1.29
8	MO112609260/0 In stock	Seeger	£1.84 £1.53
11	MO135061504/0LC In stock	Belt	£26.66 £22.22
12	MO125601571/0 Available to backorder	Pulley	£30.70 £25.58
13	MO112793102/0 In stock	Screw	£1.55 £1.29
14	MO112540260/0 Available to backorder	Washer	£1.63 £1.36
15	MO125670007/0 In stock	Washer	£1.97 £1.64
16	MO112139480/0 In stock	Feather	£1.70 £1.42
17	MO112818700/0 In stock	Screw	£1.55 £1.29
18	MO112154210/0 Available to backorder	Nut	£1.70 £1.42
21	MO112691910/0 Available to backorder	Screw	£1.73 £1.44
22	MO112524010/0 Available to backorder	Washer	£1.84 £1.53
23	MO112610800/0 In stock	Seeger	£1.70 £1.42
24	MO119216048/0 In stock	Bearing	£18.31 £15.26
25	MO125601606/0 Available to backorder	Pulley From S.N DD281615	£30.97 £25.81
26	MO125160056/0 Available to backorder	Spacer	£4.64 £3.87
27	MO325318232/0 Available to backorder	Lever	£7.74 £6.45
28	MO112293201/0 In stock	Nut	£1.70 £1.42
29	MO112155020/0 In stock	Nut	£1.70 £1.42
30	MO125670022/0 In stock	Washer	£1.97 £1.64
31	MO125040635/0 In stock	Bushing	£4.37 £3.64
32	MO382004618/0 In stock	Wire	£22.82 £19.02
33	MO125160086/0 Available to backorder	Spacer	£7.46 £6.22
