TORNADO 2098 AP - 2017-2018 - 2T0510401/AP17 - Stiga Ride On Mower Carburettor Diagram

Description

Stiga TORNADO 2098 AP Parts Diagram

Product Name - TORNADO 2098 AP

Model Year - 2017-2018

Model Type - SD 98

Art.N - 2T0510401/AP17

Engine Model -

	Part No.	Details
1	MO118551217/0 Available to backorder	Cover Assy	£50.69 £42.24
2	MO118551273/0 Available to backorder	Container	£2.94 £2.45
3	MO118550527/0 Available to backorder	Pre-Filter	£7.02 £5.85
5	MO112791213/1 In stock	Screw	£1.55 £1.29
6	MO118550237/0 Available to backorder	Nut	£3.38 £2.82
7	MO118550236/0 Available to backorder	Starter Cup	£6.06 £5.05
8	MO118550235/1 Available to backorder	Flywheel Fan	£24.05 £20.04
9	MO118550234/2 Available to backorder	Flywheel Ass.Y	£215.46 £179.55
10	MO118550214/0 In stock	Start Motor Assy	£154.86 £129.05
11	MO112691100/0 Available to backorder	Screw	£1.63 £1.36
12	MO118550210/1 Available to backorder	Coil Assy. Charge	£56.56 £47.13
13	MO118550209/1 In stock	Elettronic Coil	£41.74 £34.78
14	MO118550448/0 Available to backorder	Spark Plug Terminal	£16.16 £13.47
15	3381 In stock	Spark Plug	£4.20 £3.50
16	MO118550208/1 In stock	Rectfier	£48.91 £40.76
17	MO118550207/1 Available to backorder	Output Wire. Rectifier	£12.94 £10.78
18	MO118550331/1 Available to backorder	Remote Control Assy	£42.22 £35.18
20	MO118550213/0 Available to backorder	Spring	£2.11 £1.76
21	MO118551219/0 Available to backorder	Governor Link	£5.34 £4.45
22	MO118551218/0 Available to backorder	Rod Choke	£4.78 £3.98
24	MO118551221/0 Available to backorder	Throttle Rod	£2.94 £2.45
26	MO118550435/1 In stock	Carburettor	£83.75 £69.79
27	MO118550225/1 Available to backorder	Breather Fuel Pipe	£8.86 £7.38
28	MO118550320/1 Available to backorder	Intake Manifold Assy	£30.98 £25.82
30	MO118550322/0 Available to backorder	Air Cleaner Cover	£30.90 £25.75
31	MO118550321/0 In stock	Air Filter	£16.74 £13.95
32	MO118550764/0 Available to backorder	Air Filter Gasket	£5.65 £4.71
33	MO112292102/0 In stock	Nut	£1.70 £1.42
34	MO118550432/0 Available to backorder	Fuel Pipe	£2.82 £2.35
35	MO118550427/0 In stock	Fuel Filter	£5.47 £4.56
36	MO118551279/0 Available to backorder	Double-Screw Bolt	£3.79 £3.16
37	MO118551263/0 Available to backorder	Intake Manifold Gasket	£1.84 £1.53
38	MO118550220/0 Available to backorder	Intake Manifold	£32.38 £26.98
39	MO118551262/0 Available to backorder	Carburetor Gasket	£1.84 £1.53
40	MO118551259/0 In stock	Guard	Was £20.84 £17.37 Special Price £13.24 £11.03
45	MO118550365/1 Available to backorder	Kit Repair	£50.69 £42.24
46	MO118550332/1 Available to backorder	Brushhold	£35.20 £29.33
47	MO118550440/0 Available to backorder	Kit Repair. Carburettor	£10.42 £8.68
48	MO118550442/0 Available to backorder	Carburettor Gasket Set	£15.78 £13.15
