Tanaka TPS-270S - Engine 2

Part No. tpstps270sengine2-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Tanaka TPS-270S - Engine 2

Tanaka TPS-270S - Engine 2

Description

Tanaka TPS-270S Chainsaw - Engine 2 Parts Diagram

Ref.		Img.	Part No.	Details
	1		TK6685690 Available to backorder	Cylinder Cover		£8.59 £7.16
	4		TK6695504 Available to backorder	Hex.Hole Bolt 5X16.Ps		£1.79 £1.49
	5		TK6684638 Available to backorder	Hex Hole Bolt 5X10		£1.78 £1.48
	6		TK6697455 In stock	Washer 6		£0.35 £0.29
	16		TK6692732 Available to backorder	Muffler Gasket		£1.78 £1.48
	21		TK6692813 Available to backorder	Muffler Protector		£8.23 £6.86
	24		TK6695508 Available to backorder	Hex. Hole Bolt 4X18Ws		£1.78 £1.48
	30		TK6688345 Available to backorder	Plug Cap		£5.38 £4.48
	31		TK6684642 Available to backorder	Clutch Washer B		£1.78 £1.48
	32		TK6684643 Available to backorder	Clutch Shoe Comp.		£9.64 £8.03
	33		TK6684644 Available to backorder	Clutch Spring		£1.78 £1.48
	34		TK6684645 Available to backorder	Clutch Plate A 0.6		£1.78 £1.48
	35		TK6684646 Available to backorder	Step Bolt		£1.74 £1.45
	36		TK6684634 In stock	Hex.Hole Bolt 5X20Ps		£1.85 £1.54
	38		TK6684648 Available to backorder	Bent Washer 8		£1.58 £1.32
	45		TK6684636 Available to backorder	Tapping Screw 4.5X16		£1.78 £1.48
	73		TK6687264 Available to backorder	Heat Shield		£5.38 £4.48

Description

Tanaka TPS-270S Chainsaw - Engine 2 Parts Diagram
