Stihl MS180 C-BE - Ignition System - Av System - Parts Diagram

Name: Stihl MS180 C-BE - Ignition System - Av System - Parts Diagram
SKU: ms180_c_be_ignition_system_av_system-group
Price: 0.57 GBP
Availability: InStock

Part No. ms180_c_be_ignition_system_av_system-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Stihl MS180 C-BE - Ignition System - Av System - Parts Diagram

Description

Stihl MS180 C-BE - Ignition System - Av System - Parts Diagram

	Part No.	Details
1	ST1130 400 1201 Available to backorder	Flywheel	£64.92 £54.10
2	ST0000 955 0802 In stock	Collar nut M8x1	£1.39 £1.16
3	ST1130 400 1302 Available to backorder	Ignition module (Contains 45416)	£54.85 £45.71
4	ST1128 405 1000 In stock	Spark plug boot	£6.84 £5.70
5	ST0000 998 0604 In stock	Spark plug contact spring	£1.43 £1.19
6	ST1130 440 1101 Available to backorder	Short circuit wire	£4.09 £3.41
7	ST1130 405 8000 Available to backorder	Insulator	£2.63 £2.19
8	ST1130 440 2201 Available to backorder	Ground wire 125 mm / 4 15/16"	£3.31 £2.76
9	ST1130 448 1201 Available to backorder	Lead retainer	£2.63 £2.19
10	ST9075 478 4155 In stock	Pan head self-tapping screw IS-D5x24	£0.95 £0.79
20	ST1130 791 5900 Available to backorder	Stop buffer	£4.00 £3.33
21	ST1123 791 2800 Available to backorder	Annular buffer	£7.18 £5.98
24	ST1123 791 7300 In stock	Plug	£0.83 £0.69
25	ST1123 791 7305 In stock	Plug	£0.68 £0.57
