Stihl HL94 KC-E - Control Handle - Parts Diagram

Description

Stihl HL94 KC-E - Control Handle - Parts Diagram

	Part No.	Details
1	ST4149 790 1307 Available to backorder	Control handle (Contains 2 - 20)	£59.75 £49.79
2	ST4149 790 1101 Available to backorder	Handle molding	£34.92 £29.10
3	ST4149 798 2100 Available to backorder	Thumbwheel	£5.23 £4.36
4	ST4149 791 3102 Available to backorder	Spring	£2.15 £1.79
5	ST4149 182 2802 Available to backorder	Lever	£4.32 £3.60
6	ST9104 003 2962 Available to backorder	Self-tapping screw P4x10	£0.79 £0.66
7	ST4149 791 3101 Available to backorder	Spring	£2.40 £2.00
8	ST4149 442 1601 Available to backorder	Contact spring	£1.60 £1.33
9	ST4149 442 1600 Available to backorder	Contact spring	£1.60 £1.33
10	ST4144 791 9400 Available to backorder	Hose clamp	£3.52 £2.93
11	ST9022 341 0960 In stock	Spline screw IS-M5x12	£0.83 £0.69
12	ST4149 182 2801 Available to backorder	Lever	£4.45 £3.71
13	ST4128 182 4501 Available to backorder	Torsion spring	£1.14 £0.95
14	ST4149 182 0800 Available to backorder	Lockout lever	£4.45 £3.71
15	ST4149 182 2800 Available to backorder	Lever	£4.45 £3.71
16	ST4149 182 4500 Available to backorder	Torsion spring	£1.37 £1.14
17	ST4149 182 1000 In stock	Throttle trigger	£7.32 £6.10
18	ST9074 478 2967 Available to backorder	Pan head self-tapping screw IS-P4x10	£0.79 £0.66
19	ST4149 180 1105 Available to backorder	Throttle cable	£26.06 £21.72
20	ST9074 478 3025 In stock	Pan head screw IS P4x16	£0.79 £0.66
21	ST4149 790 1300 Available to backorder	Control handle (Contains 2 - 18 + 20 + 22)	£61.08 £50.90
22	ST4149 180 1101 Available to backorder	Throttle cable	£24.35 £20.29
23	ST4180 790 3405 In stock	Loop handle (Contains 24 - 28)	£22.52 £18.77
24	ST4130 790 8450 Available to backorder	Bow (Contains 25 + 26)	£16.16 £13.47
25	ST9222 068 0900 In stock	Square nut M6	£0.48 £0.40
26	ST9022 341 1370 In stock	Pan head screw IS M6x30	£1.31 £1.09
27	ST4123 791 7400 Available to backorder	Strap	£5.46 £4.55
28	ST9291 021 0140 In stock	Washer 6.4	£0.37 £0.31
