SB 44 D - 2012-2015 - 280321002/12 - Stiga Brushcutter Gear Case Diagram

Name: SB 44 D - 2012-2015 - 280321002/12 - Stiga Brushcutter Gear Case Diagram
SKU: sb_44_d_280321002_12_gear_case-group
Price: 1.05 GBP
Availability: InStock

Part No. sb_44_d_280321002_12_gear_case-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

SB 44 D - 2012-2015 - 280321002/12 - Stiga Brushcutter Gear Case Diagram

Description

Stiga SB 44 D Parts Diagram

Product Name - SB 44 D

Model Year - 2012-2015

Model Type - B 44 D

Art.N - 280321002/12

Engine Model -

	Part No.	Details
1	MO118801370/0 Available to backorder	Gear Case Assy	£96.42 £80.35
6	MO112727801/0 Available to backorder	Screw	£1.63 £1.36
7	MO112789000/0 Available to backorder	Screw	£1.63 £1.36
8	MO112727794/0 Available to backorder	Screw	£1.39 £1.16
10	MO123670002/0 Available to backorder	Guard	£1.33 £1.11
15	MO123250002/0 Available to backorder	Upper Ring Nut	£5.65 £4.71
16	MO123250003/0 Available to backorder	Lower Ring Nut	£4.37 £3.64
18	MO123120015/0 Available to backorder	Nut	£1.63 £1.36
21	MO118801305/0 Available to backorder	Support	£5.22 £4.35
22	MO2135050 Available to backorder	Screw	£1.33 £1.11
23	MO2135180 Available to backorder	Screw	£1.40 £1.17
24	MO118801379/0 Available to backorder	Safety Cover. Grey	£18.16 £15.13
25	MO9943-0516-16 In stock	Screw	£1.26 £1.05
27	MO112728099/1 Available to backorder	Screw	£1.63 £1.36
28	MO123311013/0 Available to backorder	Line Cutter Blade	£3.25 £2.71
32	MO1911-9262-01 In stock	3 Teeth Disc	£9.55 £7.96
