PARK 500 WX - 2025 - 2F6130535/ST2 - Stiga Front Mower Oil Pan Diagram

Description

Stiga PARK 500 WX Parts Diagram

Product Name - PARK 500 WX Special

Model Year - 2025

Model Type - P 901 C4W

Art.N - 2F6130535/ST2

Engine Model - Honda GCV530

Be the first to review this product

0 product questions

	Part No.	Details
1	HP11300-Z0A-811 Available to backorder	Pan Assy. Oil	£194.04 £161.70
6	HP15550-Z0A-810 Available to backorder	Cap Assy. Drain	£8.83 £7.36
7	HP15625-ZE1-003 Available to backorder	Packing. Oil Filler Cap	£4.57 £3.81
8	HP16510-Z0A-000 Available to backorder	Governor Assy.	£29.29 £24.41
9	HP16511-Z0A-000 Available to backorder	Weight. Governor	£2.99 £2.49
10	HP16512-Z0A-000 Available to backorder	Holder. Governor Weight	£17.33 £14.44
11	HP16513-ZE2-000 Available to backorder	Pin. Governor Weight	£1.42 £1.18
12	HP16520-Z0A-000 Available to backorder	Shaft Comp. Governor	£52.32 £43.60
13	HP16531-Z0A-000 Available to backorder	Slider. Governor	£3.13 £2.61
14	HP90473-147-000 Available to backorder	Washer. 6X16	£3.73 £3.11
15	HP90602-ZE1-000 Available to backorder	Clip. Governor Holder	£3.70 £3.08
16	HP91202-Z0A-003 In stock	Oil Seal. 31X50X8	£10.66 £8.88
17	HP91206-333-003 Available to backorder	Oil Seal. 10X16X4.5	£5.90 £4.92
21	HP94101-06800 Available to backorder	Washer. Plain. 6mm	£0.96 £0.80
23	HP94301-08140 Available to backorder	Dowel Pin. 8X14	£3.04 £2.53
25	HP95701-0601608 Available to backorder	Bolt. Flange. 6X16	£1.46 £1.22
