PARK 500 WX - 2025 - 2F6130535/ST2 - Stiga Front Mower Cylinder Diagram

Description

Stiga PARK 500 WX Parts Diagram

Product Name - PARK 500 WX Special

Model Year - 2025

Model Type - P 901 C4W

Art.N - 2F6130535/ST2

Engine Model - Honda GCV530

	Part No.	Details
1	HP12100-Z0A-407 Available to backorder	Cylinder Comp.	£291.36 £242.80
2	HP12209-422-005 Available to backorder	Seal. Valve Stem	£17.57 £14.64
3	HP12311-Z0A-000 Available to backorder	Cover. Head	£20.87 £17.39
5	HP17101-Z0A-000 Available to backorder	Manifold. Intake	£247.08 £205.90
6	HP17151-Z0A-000 In stock	Packing. Intake Manifold	£8.02 £6.68
8	HP90013-883-000 Available to backorder	Bolt. Flange. 6X12 (Ct200)	£4.34 £3.62
10	HP90045-892-000 Available to backorder	Bolt. Stud. 6X28 (Ct200)	£6.06 £5.05
11	HP90201-Z0A-000 Available to backorder	Nut. Flange. 8mm	£2.64 £2.20
13	HP95701-0603000 Available to backorder	Bolt. Flange. 6X30	£1.55 £1.29
14	2135 In stock	Plug. Spark (Bpr5Es) (Ngk)	£2.78 £2.32
14	HP98079-55855 Available to backorder	Plug. Spark (W16Epr-U) (Denso)	£5.17 £4.31
22	MO118552487/0 Available to backorder	Exhaust Pipe Gasket	£7.84 £6.53
