PARK 420 LM - 2014-2015 - 13-6384-12 - Stiga Front Mower Assembly Parts Diagram

Name: PARK 420 LM - 2014-2015 - 13-6384-12 - Stiga Front Mower Assembly Parts Diagram
SKU: park_420_lm_13_6384_12_assembly_parts-group
Price: 1.29 GBP
Availability: InStock

Part No. park_420_lm_13_6384_12_assembly_parts-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PARK 420 LM - 2014-2015 - 13-6384-12 - Stiga Front Mower Assembly Parts Diagram

Description

Stiga PARK 420 LM Parts Diagram

Product Name - PARK 420 LM

Model Year - 2014-2015

Model Type - P 901 CH

Art.N - 13-6384-12

Engine Model - B&S PowerBuilt 3130 AVS

	Part No.	Details
1	MO9595-0262-00 In stock	Locating Pin	£1.79 £1.49
2	MO9699-0103-02 Available to backorder	Washer 1.0 mm	£2.12 £1.77
3	MO9699-0114-02 Available to backorder	Washer 1.0 mm	£1.97 £1.64
10	MO1134-4734-01 In stock	Ignition Key	£17.33 £14.44
13	MO1134-5512-01 Available to backorder	Towing Plate	£20.40 £17.00
14	MO9959-0820-16 Available to backorder	Screw	£1.55 £1.29
15	MO112154220/0 Available to backorder	Nut	£1.63 £1.36
17	MO1134-6113-02 Available to backorder	Screw	£12.94 £10.78
18	MO9898-1035-16 Available to backorder	Screw	£2.82 £2.35
19	MO9739-1031-22 In stock	Nut	£1.97 £1.64
