PARK 345 PWX - 2021 - 2F6130535/ST1P - Stiga Front Mower Carburettor Diagram

Name: PARK 345 PWX - 2021 - 2F6130535/ST1P - Stiga Front Mower Carburettor Diagram
SKU: park_345_pwx_2f6130535_st1p_carburettor-group
Price: 0.87 GBP
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PARK 345 PWX - 2021 - 2F6130535/ST1P - Stiga Front Mower Carburettor Diagram

Description

Stiga PARK 345 PWX Parts Diagram

Product Name - PARK 345 PWX

Model Year - 2021

Model Type - P 901 C 4W

Art.N - 2F6130535/ST1P

Engine Model - Honda GCV 530

Be the first to review this product

0 product questions

	Part No.	Details
1	HP16010-Z0A-L32 Available to backorder	Gasket Set	£24.43 £20.36
2	HP16011-Z0A-004 Available to backorder	Valve. Float	£28.07 £23.39
3	HP16013-Z0A-004 Available to backorder	Float Set	£27.24 £22.70
4	HP16015-Z0A-802 Available to backorder	Chamber Set. Float	£69.24 £57.70
5	HP16016-Z0A-004 Available to backorder	Screw Set	£14.04 £11.70
6	HP16024-Z0A-004 Available to backorder	Screw Set. Drain	£14.04 £11.70
7	HP16028-Z0A-L32 Available to backorder	Screw Set. Pilot	£18.56 £15.47
8	HP16100-Z0A-L32 Available to backorder	Carburetor Assy. (Bw02D A)	£260.64 £217.20
9	HP16139-Z0A-L32 Available to backorder	Cover Set. Air Vent	£48.84 £40.70
10	HP16168-Z0A-004 Available to backorder	Cap	£6.18 £5.15
11	HP16178-Z0A-802 Available to backorder	Gasket	£6.70 £5.58
12	HP16200-Z0A-802 Available to backorder	Valve Assy. Solenoid	£71.47 £59.56
13	HP16211-Z0A-000 Available to backorder	Insulator. Carburetor	£11.98 £9.98
14	HP16212-Z0A-000 In stock	Packing. Insulator	£4.94 £4.12
15	HP17228-Z0A-003 In stock	Packing. Air Cleaner	£3.24 £2.70
16	HP90659-680-013 Available to backorder	Clip. Wire Harness	£6.68 £5.57
17	HP95002-02080 Available to backorder	Clip. Tube (B8)	£1.08 £0.90
18	HP95002-02650 Available to backorder	Clip. Tube (B6.5)	£1.04 £0.87
19	HP95003-070-3031 Available to backorder	Tube. Vinyl. 4X7X300 (95003-07001-60M)	£1.58 £1.32
20	HP95005-454-0020S Available to backorder	Tube. 4.5X400 (95005-45001-20M)	£7.42 £6.18
21	HP99131-Z0A-0920 Available to backorder	Jet. Main. #92.5	£25.86 £21.55
22	HP99131-Z0A-0930 Available to backorder	Jet. Main. #93.8	£25.86 £21.55
23	HP99135-Z0A-0370 Available to backorder	Jet. Pilot. #37.5	£28.40 £23.67
24	HP16017-Z0A-801 Available to backorder	Screw	£5.40 £4.50
