PARK 345 PWX - 2021 - 2F6130535/ST1 - Stiga Front Mower Starter Motor Diagram

Part No. park_345_pwx_2f6130535_st1_starter_motor-group
PARK 345 PWX - 2021 - 2F6130535/ST1 - Stiga Front Mower Starter Motor Diagram
PARK 345 PWX - 2021 - 2F6130535/ST1 - Stiga Front Mower Starter Motor Diagram

Description

Stiga PARK 345 PWX Parts Diagram

Product Name - PARK 345 PWX

Model Year - 2021

Model Type - P 901 C 4W

Art.N - 2F6130535/ST1

Engine Model - Honda GCV 530

Ref. Img. Part No. Details
  1 Ring. Snap (Denso)
Ring. Snap (Denso)
HP30201-PH9-004
Available to backorder
Ring. Snap (Denso)
£1.97 £1.64

  2 Collar Set. Clutch Stop
Collar Set. Clutch Stop
HP30202-PZ1-003
Available to backorder
Collar Set. Clutch Stop
£18.76 £15.63

  3 Motor Assy. Starter
Motor Assy. Starter
HP31200-Z0A-013
Available to backorder
Motor Assy. Starter
£543.60 £453.00

  4 Switch Assy. Magnet
Switch Assy. Magnet
HP31204-Z0A-013
Available to backorder
Switch Assy. Magnet
£202.08 £168.40

  5 Clutch Comp. Overrunning
Clutch Comp. Overrunning
HP31207-Z0A-003
Available to backorder
Clutch Comp. Overrunning
£164.88 £137.40

  6 Housing Comp. Drive Side
Housing Comp. Drive Side
HP31208-Z0A-003
Available to backorder
Housing Comp. Drive Side
£99.60 £83.00

  7 Bearing A
Bearing A
HP31209-PH9-004
Available to backorder
Bearing A
£8.21 £6.84

  8 Brush
Brush
HP31211-PH9-004
Available to backorder
Brush
£15.37 £12.81

  9 Spring. Brush
Spring. Brush
HP31212-PH9-004
Available to backorder
Spring. Brush
£5.60 £4.67

  10 Bolt. Through
Bolt. Through
HP31214-PH9-004
Available to backorder
Bolt. Through
£9.40 £7.83

  11 Armature Comp.
Armature Comp.
HP31217-Z0A-003
Available to backorder
Armature Comp.
£358.68 £298.90

  12 Yoke Comp.
Yoke Comp.
HP31218-PH9-004
Available to backorder
Yoke Comp.
£278.88 £232.40

  13 Frame Comp. Commutator End
Frame Comp. Commutator End
HP31219-Z0A-003
Available to backorder
Frame Comp. Commutator End
£60.40 £50.33

  14 Nut. Hex. 8mm
Nut. Hex. 8mm
HP31220-PH9-004
Available to backorder
Nut. Hex. 8mm
£7.46 £6.22

  15 Nut. Hex. (6mm)
Nut. Hex. (6mm)
HP31223-PA0-006
Available to backorder
Nut. Hex. (6mm)
£3.84 £3.20

  16 Holder. Brush
Holder. Brush
HP31231-PH9-004
Available to backorder
Holder. Brush
£52.99 £44.16

  17 Insulator. Brush Holder
Insulator. Brush Holder
HP31233-PH9-004
Available to backorder
Insulator. Brush Holder
£40.66 £33.88
