McCulloch SuperLite 4528 - 9666933-01 - 2012-02 - Mower Deck - Cutting Deck Parts Diagram

Name: McCulloch SuperLite 4528 - 9666933-01 - 2012-02 - Mower Deck - Cutting Deck Parts Diagram
SKU: superlite_4528_96669-_mower_deck_cutting_deck-group
Price: 1.08 GBP
Availability: InStock

Part No. superlite_4528_96669-_mower_deck_cutting_deck-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

McCulloch SuperLite 4528 - 9666933-01 - 2012-02 - Mower Deck - Cutting Deck Parts Diagram

Description

McCulloch SuperLite 4528 - 9666933-01 - 2012-02 - Mower Deck - Cutting Deck Parts Diagram

	Part No.	Details
1	HV731 71 14-51 Available to backorder	Hexagon Nut Flange	£1.84 £1.53
2	HV731 23 14-01 In stock	Hexagon Nut	£1.30 £1.08
3	HV525 35 08-01 Available to backorder	Bar	£51.25 £42.71
4	HV525 35 16-01 Available to backorder	Wear Plate	£14.27 £11.89
5	HV577 24 96-01 Available to backorder	Blade Hedge Trimmer	£75.84 £63.20
6	HV525 35 11-01 Available to backorder	Bar	£11.16 £9.30
7	HV525 35 19-01 In stock	Spacer	£2.82 £2.35
8	HV525 75 51-05 In stock	Screw Itxscfm	£1.63 £1.36
9	HV525 35 20-01 Available to backorder	Bracket	£4.76 £3.97
10	HV525 75 51-03 Available to backorder	Screw Itxscfm	£2.40 £2.00
