Husqvarna Zthe6125 - Fuel Tank

Husqvarna Zthe6125 - Fuel Tank

Part No. zthe6125_2002_01_fuel_tank-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Husqvarna Zthe6125 - Fuel Tank

Husqvarna Zthe6125 - Fuel Tank

Description

Husqvarna Zthe6125

Model Year - 2002-01

Fuel Tank - Parts Diagram

Ref.		Img.	Part No.	Details
	-1		HV539 10 26-50 Available to backorder	Connection		£7.70 £6.42
	0		HV539 91 22-22 Available to backorder	Clamp		£1.40 £1.17
	1		HV539 99 02-09 Available to backorder	Screw		£4.22 £3.52
	2		HV539 10 26-79 Available to backorder	Valve		£46.80 £39.00
	3		HV539 99 01-84 Available to backorder	Nut		£2.44 £2.03
	4		HV539 10 44-09 Available to backorder	Tank Unit		£163.56 £136.30
	5		HV539 99 01-87 Available to backorder	Washer		£2.56 £2.13

Description

Husqvarna Zthe6125

Model Year - 2002-01

Fuel Tank - Parts Diagram
