Description

Husqvarna P 525D WITH CABIN

Model Year -

Cabin 2 - Parts Diagram

	Part No.	Details
1	HV579 85 73-01 Available to backorder	Frame	£1,774.15 £1,478.46
2	HV579 85 74-01 Available to backorder	Insulation	£111.48 £92.90
3	HV579 85 75-01 Available to backorder	Grommet	£2.30 £1.92
4	HV579 85 76-01 Available to backorder	Sealing Plug	£2.45 £2.04
5	HV579 85 77-01 Available to backorder	Sealing Plug	£2.88 £2.40
6	HV579 85 78-01 Available to backorder	Plug	£6.20 £5.17
7	HV579 85 86-01 Available to backorder	Cover	£0.43 £0.36
8	HV579 85 79-01 Available to backorder	Console	£944.27 £786.89
9	HV579 86 10-01 Available to backorder	Washer	£2.30 £1.92
10	HV734 48 80-01 Available to backorder	Washer	£2.30 £1.92
12	HV732 21 14-01 Available to backorder	Lock Nut	£1.55 £1.29
13	HV501 94 86-01 Available to backorder	Arm	£121.20 £101.00
14	HV501 95 51-01 Available to backorder	Scraper	£90.60 £75.50
15	HV501 95 52-01 Available to backorder	Bushing	£7.93 £6.61
16	HV501 95 53-01 Available to backorder	Motor	£261.84 £218.20
17	HV579 86 11-01 Available to backorder	Hinge	£39.65 £33.04
18	HV579 86 27-01 Available to backorder	Panel	£501.74 £418.12
19	HV531 11 94-26 Available to backorder	Screw	£1.51 £1.26
20	HV579 86 39-01 Available to backorder	Screw	£2.05 £1.71
21	HV579 85 87-01 Available to backorder	Screw	£2.05 £1.71
22	HV579 86 41-01 Available to backorder	Screw	£1.28 £1.07
23	HV579 86 43-01 Available to backorder	Tank	£78.72 £65.60
24	HV729 91 69-01 Available to backorder	Screw Dvpan	£2.86 £2.38
25	HV579 86 44-01 Available to backorder	Washer	£2.83 £2.36
26	HV579 86 45-01 Available to backorder	Washer	£2.30 £1.92
27	HV579 86 76-01 Available to backorder	Base	£1.01 £0.84
28	HV579 86 77-01 Available to backorder	Rivet	£2.94 £2.45
29	HV579 86 78-01 Available to backorder	Door	£820.86 £684.05
30	HV579 87 07-01 Available to backorder	Door	£444.54 £370.45
31	HV501 95 54-01 Available to backorder	Screen	£305.04 £254.20
32	HV501 95 57-01 Available to backorder	Window	£108.00 £90.00
33	HV501 95 58-01 Available to backorder	Light	£245.40 £204.50
34	HV502 07 31-01 Available to backorder	Rear-View Mirror	£76.44 £63.70
35	HV501 96 21-01 Available to backorder	Handle	£37.50 £31.25
36	HV579 87 18-01 Available to backorder	Screw	£5.02 £4.18
37	HV579 87 19-01 Available to backorder	Screw	£4.74 £3.95
38	HV579 87 21-01 Available to backorder	Seal	£24.50 £20.42
39	HV579 87 22-01 Available to backorder	Plate	£49.74 £41.45
40	HV579 87 23-01 Available to backorder	Air Filter	£33.17 £27.64
41	HV579 87 30-01 Available to backorder	Nut	£8.64 £7.20
42	HV501 96 22-01 Available to backorder	Headlight	£253.20 £211.00
43	HV579 87 34-01 Available to backorder	Holder	£112.20 £93.50
44	HV581 98 69-01 Available to backorder	Light	£89.16 £74.30
45	HV579 87 05-01 Available to backorder	Cap	£0.58 £0.48
46	HV502 01 06-01 Available to backorder	Light	£291.72 £243.10
47	HV501 96 24-01 Available to backorder	Light	£84.36 £70.30
48	HV579 87 46-01 Available to backorder	Seal	£45.41 £37.84
49	HV579 87 47-01 Available to backorder	Seal	£25.24 £21.03
51	HV732 21 16-01 Available to backorder	Lock Nut	£1.79 £1.49
