Hayter Heritage 10-30 - 133D (133D260000001 - 133D260999999) - Chassis - Hood

Name: Hayter Heritage 10-30 - 133D (133D260000001 - 133D260999999) - Chassis - Hood
SKU: 10 30 heritage tractor 133d chassis hood-group
Price: 2.13 GBP
Availability: InStock

Part No. 10 30 heritage tractor 133d chassis hood-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Hayter Heritage 10-30 - 133D (133D260000001 - 133D260999999) - Chassis - Hood

Description

Hayter Heritage 10-30 - 133D

Serial No: 133D260000001 - 133D260999999

Chassis - Hood - Parts Diagram

	Part No.	Details
5	HAMU2X16 Available to backorder	Bolt. Carriage	£2.81 £2.34
6	HAMU1401378E701 Available to backorder	Bracket. Hinge	£104.76 £87.30
8	HAMU9X56 Available to backorder	Bolt. Shoulder	£2.89 £2.41
13	HAMU26X249 Available to backorder	Screw	£2.56 £2.13
17	HAMU1401076E701 Available to backorder	Tray. Battery	£40.26 £33.55
18	HAMU15X79 Available to backorder	Nut. Flange	£3.14 £2.62
19	BP017X45MA Available to backorder	Washer	£3.91 £3.26
21	BP092317MA Available to backorder	Cap. Fuel Tank	£12.17 £10.14
25	BP26X263MA Available to backorder	Screw	£4.20 £3.50
28	HAMU1401297E701 Available to backorder	Bracket. Prop Rod	£33.85 £28.21
31	HAMU1401248 Available to backorder	Control. Throttle	£36.00 £30.00
36	HAMU1401229 Available to backorder	Footmat. Left	£19.91 £16.59
37	HAMU1401228 Available to backorder	Footmat. Right	£20.05 £16.71
39	HAMU1401371E701 Available to backorder	Frame	£191.76 £159.80
40	HAMU1401349E701 Available to backorder	Deck. Seat	£682.39 £568.66
44	HAMU7601036 Available to backorder	Kit. Foil Heat Shield	£53.14 £44.28
50	BP698183 In stock	Valve. Fuel Shut-Off	£9.91 £8.26
51	HAMU1401401 Available to backorder	Shield. Heat	£46.99 £39.16
