Stihl FSA400.0 - Electric Motor, Motor Housing - Parts Diagram

Name: Stihl FSA400.0 - Electric Motor, Motor Housing - Parts Diagram
SKU: fsa400_0_electric_motor_motor_housing-group
Price: 0.3 GBP
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Stihl FSA400.0 - Electric Motor, Motor Housing - Parts Diagram

Description

Stihl FSA400.0 - Electric Motor, Motor Housing - Parts Diagram

Be the first to review this product

0 product questions

	Part No.	Details
1	STFA09 600 3410 Available to backorder	Flange (Contains 2 - 6)	£141.90 £118.25
2	ST9075 478 4720 Available to backorder	Pan head self-tapping screw IS-D6x35	£1.22 £1.02
3	ST9291 021 0140 In stock	Washer 6.4	£0.36 £0.30
4	ST9503 003 8759 Available to backorder	Grooved ball bearing DIN625-6803-2RS	£8.80 £7.33
5	ST9503 003 5129 Available to backorder	Grooved ball bearing DIN625-6001-2RS-C3	£11.12 £9.27
6	ST9456 621 3100 Available to backorder	Circlip 28x1.2	£1.22 £1.02
7	STFA09 600 1100 Available to backorder	Rotor	£159.50 £132.92
8	ST9455 021 1131 Available to backorder	Circlip 12x1	£0.66 £0.55
9	ST9022 313 0610 Available to backorder	Spline screw IS-M4x6	£0.66 £0.55
10	STFA09 600 4400 Available to backorder	Spiral housing	£15.18 £12.65
11	ST9075 478 4136 In stock	Pan head self-tapping screw IS-D5x20	£0.89 £0.74
12	STFA09 706 3400 Available to backorder	Cover	£8.36 £6.97
13	ST9074 477 2980 Available to backorder	Pan head self-tapping screw IS-P4x12	£0.76 £0.63
14	STFA09 122 2400 Available to backorder	Bellows	£4.30 £3.58
15	STFA09 080 1900 Available to backorder	Filter (Contains 16)	£4.84 £4.03
16	ST9022 319 1028 In stock	Screw IS-M5x14	£0.76 £0.63
17	STFA09 600 0802 Available to backorder	Motor housing (Contains 18 - 23)	£189.20 £157.67
18	STFA03 955 1000 Available to backorder	Square nut	£1.10 £0.92
19	STFA09 084 0900 Available to backorder	Shroud	£24.76 £20.63
20	STFA09 718 7400 Available to backorder	Guard plate	£7.48 £6.23
21	STFA09 967 1500 Available to backorder	Model plate FSA 400	£4.52 £3.77
22	STFA09 609 0100 Available to backorder	Gasket	£7.70 £6.42
23	STFA09 791 2800 Available to backorder	Annular buffer	£4.84 £4.03
24	STFA09 430 1400 Available to backorder	Electronic module	£230.52 £192.10
25	STFA09 440 3005 Available to backorder	Wiring harness	£22.54 £18.78
26	ST9022 341 0960 In stock	Spline screw IS-M5x12	£0.77 £0.64
27	ST9074 477 4132 In stock	Pan head self-tapping screw IS-P5x18	£0.88 £0.73
29	STFA09 400 9400 Available to backorder	Battery compartment (Contains 30 - 33)	£47.86 £39.88
30	STHA02 007 1001 Available to backorder	Spring kit (Contains 31)	£2.32 £1.93
31	STMA01 791 3100 Available to backorder	Spring	£2.32 £1.93
32	STHA02 430 9800 Available to backorder	Lockout lever (Contains 33)	£7.48 £6.23
33	ST0000 997 2201 In stock	Spring	£1.32 £1.10
34	STFA09 007 4900 Available to backorder	Buffer kit (Contains 23)	£22.00 £18.33
