ESTATE 5102 HW - 2019 - 2T1720681/STX - Stiga Ride On Mower Cylinder Diagram

Name: ESTATE 5102 HW - 2019 - 2T1720681/STX - Stiga Ride On Mower Cylinder Diagram
SKU: estate_5102_hw_2t1720681_stx_cylinder-group
Price: 1.16 GBP
Availability: InStock

Part No. estate_5102_hw_2t1720681_stx_cylinder-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

ESTATE 5102 HW - 2019 - 2T1720681/STX - Stiga Ride On Mower Cylinder Diagram

Description

Stiga ESTATE 5102 HW Parts Diagram

Product Name - ESTATE 5102 HW

Model Year - 2019

Model Type - NJS 102 Hydro

Art.N - 2T1720681/STX

Engine Model - FS481V

	Part No.	Details
3	MO118550963/0 Available to backorder	Gasket Kawasaki p.n 11061-7083	£14.11 £11.76
10	MO118551072/0 Available to backorder	Oil Seal Kawasaki p.n 92049-7001	£19.92 £16.60
15	MO118550968/0 Available to backorder	Gasket Kawasaki p.n 11061-7094	£20.69 £17.24
20	MO118551075/0 Available to backorder	Oil Seal Kawasaki p.n 92049-7028	£25.31 £21.09
23	MO112735405/0 Available to backorder	Screw Kawasaki p.n 130AA0625	£1.55 £1.29
24	MO112691400/0 Available to backorder	Screw Kawasaki p.n 92153-7054	£1.55 £1.29
25	MO112735699/0 Available to backorder	Screw Kawasaki p.n 92153-7043	£1.39 £1.16
