Countax K1850 - From 01-01-2005 To 01-01-2006 - 16 Powered Grass Collector

Name: Countax K1850 - From 01-01-2005 To 01-01-2006 - 16 Powered Grass Collector
SKU: k1850_01012005_01012006_16-group
Price: 0.28 GBP
Availability: InStock

Part No. k1850_01012005_01012006_16-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Countax K1850 - From 01-01-2005 To 01-01-2006 - 16 Powered Grass Collector

Description

Countax K Series

K1850 - Tractor

From 01-01-2005 To 01-01-2006

16 Powered Grass Collector Parts Diagram

	Part No.	Details
1	WE328955700 Available to backorder	A Series PGC Body 2003	£1,200.10 £1,000.08
2	WE178966300 Available to backorder	2002 PGC Locking Handle	£60.48 £50.40
2	WE307177800 Available to backorder	Universal Sweeper Locking Plate April 01 (2b)	£41.86 £34.88
3	WE30149800 Available to backorder	LH PGC Lever Lock	£11.42 £9.52
4	WE30150300 Available to backorder	RH PGC Lever Lock	£11.63 £9.69
5	WE028002900 Available to backorder	Bolt M6X25 Plated	£0.60 £0.50
7	7578 In stock	Nut M6 Nyloc	£0.48 £0.40
8	WE183009800 Available to backorder	2050 Sweeper Idler Shaft	£29.69 £24.74
9	WE31306200 Available to backorder	PTO End Spacer	£36.54 £30.45
10	WE301043800 Available to backorder	2050 PGC Shaft Carrier	£38.52 £32.10
11	WE10811600 In stock	Bearing (PTO Housing)	£17.52 £14.60
12	WE32727600 Available to backorder	3 Pulley (Non Keyed)	£24.25 £20.21
13	WE08819900 In stock	Dome Washer 1.34Od X 38Id X 18Dome	£15.24 £12.70
14	2139 In stock	M10 X 20mm Bolt BZP	£0.48 £0.40
15	WE27106601 In stock	Bearing Housing 17mm	£30.67 £25.56
16	WE22950300 Available to backorder	A38 Super 2 PGC Side Belt A2050 PGC	£25.60 £21.33
17	WE174004400 In stock	390L Brush Stock	£114.96 £95.80
18	WE14832900 In stock	Brush Drive Moulding Large	£4.60 £3.83
19	WE14834100 In stock	Brush Drive Moulding Small	£4.57 £3.81
21	8416 In stock	Bolt M8 X 50mm	£0.46 £0.38
22	8411 In stock	M6 X 45mm Hex Head Bright Zinc Plate	£0.48 £0.40
23	WE32121800 In stock	Slinger	£16.93 £14.11
24	WE327002600 In stock	Sweeper Pulley & Shaft	£202.03 £168.36
25	2112 Available to backorder	Circlip (PGC Pulley & Shaft)	£0.72 £0.60
29	2047 In stock	Nut	£0.34 £0.28
30	7274 In stock	M5 X 16mm Pozi Pan	£0.48 £0.40
31	WE31323900 In stock	Brush Stock Spindle (Short)	£39.13 £32.61
32	WE30117500 Available to backorder	Sweeper Bearing Cap	£7.20 £6.00
33	WE14898101 In stock	Yellow Sweeper Bristles Non Web 1003	£1.52 £1.27
34	WE14936301 In stock	Webbed Yellow PGC Bristle	£1.52 £1.27
35	WE14833000 In stock	Bristle Boss	£2.20 £1.83
37	8417 In stock	Washer M8 X 25 X 3 Unplated	£0.48 £0.40
38	WE31350400 Available to backorder	Sweeper Jockey Spacer	£13.39 £11.16
39	WE018005500 Available to backorder	M10 X 45 Bolt BZP	£1.66 £1.38
41	7282 In stock	Washer 10.8Id X 20.7Od X 2mm Thk	£0.38 £0.32
42	2038 In stock	M10 Nyloc Nut	£0.48 £0.40
43	WE148005400 In stock	Belt Guard C & 205	£65.05 £54.21
45	2111 In stock	M8 Nyloc Nut	£0.48 £0.40
46	WE028662700 Available to backorder	Bolt M8X65mm	£0.64 £0.53
47	WE327172400 Available to backorder	Roller Carrier C Series 2000 Assembly	£130.56 £108.80
48	WE327171800 Available to backorder	Sweep Roller Height Handle Assy	£143.04 £119.20
49	WE14804800 Available to backorder	Lever Knob	£7.74 £6.45
50	WE448004800 Available to backorder	Net Empting Actuator Loom A2050	£62.76 £52.30
51	WE30121900 Available to backorder	Bearing Shield	£4.04 £3.37
52	WE02941000 Available to backorder	Bolt M8 X 45mm (Vac)	£0.68 £0.57
53	WE183529500 Available to backorder	Cseries Deck Lift Pivot Spacer	£11.52 £9.60
54	WE183003800 In stock	PGC Belt Tension Adjust Trunnion	£33.49 £27.91
55	WE228001200 In stock	Belt A49 Super Ii	£27.20 £22.67
56	2010 Available to backorder	14 T4 Hp Washer	£0.48 £0.40
57	WE307191500 Available to backorder	2003 A2050 PGC Outer Shaft Locking Plate	£42.19 £35.16
58	WE088002300 Available to backorder	Nylon Washer (Friction Plate)	£0.68 £0.57
59	WE327010600 In stock	Roller PGC Akdseries Complete	£186.72 £155.60
61	WE31330002 Available to backorder	Roller Shaft Spacer	£21.96 £18.30
62	WE183010000 Available to backorder	2050 Roller Internal Shaft	£118.68 £98.90
63	WE528004301 Available to backorder	D1850A2050 Sweeper Roller Scraper Cable (63a)	£31.03 £25.86
64	WE20811500 In stock	PTO Jockey Pulley	£24.72 £20.60
65	7746 In stock	Bolt M8 X 25mm	£0.48 £0.40
66	WE327012100 Available to backorder	A2050 Sweeper Flap Plate Assembly	£96.72 £80.60
