Countax B250 - From 01-07-2015 To 06-04-2016 - 7 Seat Box

Name: Countax B250 - From 01-07-2015 To 06-04-2016 - 7 Seat Box
SKU: b250_01072015_06042016_7s-group
Price: 0.4 GBP
Availability: InStock

Part No. b250_01072015_06042016_7s-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Countax B250 - From 01-07-2015 To 06-04-2016 - 7 Seat Box

Description

Countax B Series

B250 - Tractor

From 01-07-2015 To 06-04-2016

7 Seat Box Parts Diagram

	Part No.	Details
3	WE549128900 Available to backorder	Box Seat Running Plate Mount	£57.80 £48.17
4	WE25858100 Available to backorder	Spring Sliding Seat	£12.52 £10.43
5	WE541148100 Available to backorder	Seat Adjustment Locking Plate	£6.89 £5.74
6	WE149589500 Available to backorder	30mm X 6mmx40mm Pvc Flat Sleeve	£3.43 £2.86
7	WE06849100 In stock	2mm R Clip	£0.48 £0.40
8	WE25812201 Available to backorder	Brake Return Spring	£9.41 £7.84
9	WE189515100 Available to backorder	Mulcher Link Rod 548mm	£3.60 £3.00
12	WE149551900 Available to backorder	Rubber Seat Spring Retainer	£9.58 £7.98
14	WE019483500 Available to backorder	M8 X 16 Flange Bolt	£1.12 £0.93
18	WE183016900 Available to backorder	Track Rod End Spacer 12.7Od X 10Id X 7	£13.12 £10.93
19	WE059169000 Available to backorder	Clevis Pin Dia8mm X 70mmlong	£6.94 £5.78
21	2192 In stock	Washer M8 X 21 X 1.6	£0.48 £0.40
22	WE01935700 Available to backorder	M8 X 35mm Bolt Compressor 119	£1.28 £1.07
24	WE019483600 In stock	M8 X 20 Flange Bolt	£0.48 £0.40
25	2175 In stock	M8X25 Flange Bolt	£0.48 £0.40
27	WE183856700 Available to backorder	Seat Running Plate Spacer	£1.80 £1.50
28	WE148996800 In stock	Stud ¼ Turn Slot Hd Dzus D1004050030	£7.76 £6.47
29	WE549128600 Available to backorder	Guard MK4 PTO Cut Out Infill	£19.57 £16.31
30	WE149496300 Available to backorder	PTO Flap Tractor He (Plastic)	£59.81 £49.84
31	WE149500000 Available to backorder	Dzus 14 Turn Retain Washer	£2.06 £1.72
32	WE149499900 In stock	Dzus Receptacle	£4.50 £3.75
