Countax A230D - 6 PTO Transmission

Name: Countax A230D - 6 PTO Transmission
SKU: a230d___6-group
Price: 0.32 GBP
Availability: InStock

Part No. a230d___6-group

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

Countax A Series

A230D - Tractor

6 Pto Transmission Parts Diagram

	Part No.	Details
1	WE327885400 Available to backorder	Transmission Jockey Pulley Link Rod Weld	£14.45 £12.04
2	2173 In stock	M10 Locknut	£0.48 £0.40
3	7282 In stock	Washer 10.8Id X 20.7Od X 2mm Thk	£0.38 £0.32
4	WE183851100 Available to backorder	Transmission Jockey Pulley Rod Trunnion	£1.99 £1.66
5	WE183019100 Available to backorder	2050 Brake Rod Tube	£13.80 £11.50
6	WE327890500 Available to backorder	Pivot Arm Welded Assembly	£2.57 £2.14
7	2192 In stock	Washer M8 X 21 X 1.6	£0.48 £0.40
8	2111 In stock	M8 Nyloc Nut	£0.48 £0.40
9	WE10872600 In stock	10mm Rod End	£20.66 £17.22
10	WE183849100 Available to backorder	Brake Rod Link	£9.71 £8.09
11	WE108000500 Available to backorder	10mm Spring Pin Short	£5.75 £4.79
12	WE108000600 Available to backorder	10mm X 1.5 Clevis Short	£16.22 £13.52
14	2038 In stock	M10 Nyloc Nut	£0.48 £0.40
15	WE183853700 Available to backorder	Forward And Reverse Rod	£9.92 £8.27
16	WE327022200 Available to backorder	2050 Brake Link Bracket	£81.00 £67.50
17	WE301048100 Available to backorder	Tractor Pedal Cassette Bearing Housing	£52.78 £43.98
18	WE327885600 Available to backorder	Chassis (Yanmar)	£165.36 £137.80
19	WE183020200 Available to backorder	2050 Diff Lock Pedal Trunnion	£12.85 £10.71
21	WE313010400 Available to backorder	2050 Diff Lock Control Rod	£56.46 £47.05
22	WE02941000 Available to backorder	Bolt M8 X 45mm (Vac)	£0.68 £0.57
23	2114 In stock	Washer M12 X 24 X 1.6	£0.48 £0.40
24	2539 In stock	M10 X 24 X 2 Tl Washer	£0.48 £0.40
25	WE321122200 Available to backorder	2050 Pedal Plate Assy	£32.40 £27.00
26	WE327889400 Available to backorder	Brake Rod Welded Assembly D2350Ln	£12.58 £10.48
27	WE307187100 Available to backorder	Belt Keeper	£17.66 £14.72
28	WE31351100 Available to backorder	Sweeper Jockey Cap	£44.03 £36.69
29	WE20811500 In stock	PTO Jockey Pulley	£24.72 £20.60
30	WE18831600 Available to backorder	Spacer Jockey Wheel	£45.41 £37.84
31	WE148987000 Available to backorder	22mm Plastic Bung Ti6	£6.35 £5.29
32	WE327890600 Available to backorder	PTO Jockey Pulley Plate Welded Assembly	£16.91 £14.09
33	WE018005700 Available to backorder	Hx Hd Bolt Zink Plt & Clear Passivated	£0.91 £0.76
34	WE329651200 Available to backorder	Asm Idler Tension Plate	£4.25 £3.54
35	WE31326100 Available to backorder	P.T.O. Bridge Spacer H.E. Tractor	£7.06 £5.88
37	7578 In stock	Nut M6 Nyloc	£0.48 £0.40
38	WE25813801 Available to backorder	Safety Switch Spring	£10.31 £8.59
39	WE25906200 In stock	Deck Tension Spring	£21.19 £17.66
40	2061 In stock	M6 Washer 6 X 12.5 X 1.6mm BZP	£0.48 £0.40
41	WE25812201 Available to backorder	Brake Return Spring	£9.41 £7.84
42	WE174008900 Available to backorder	MK3 Park Brake Engage Rod Sleeve	£22.06 £18.38
43	WE52936700 Available to backorder	Oilite Bush 58Od X 12Id X 12Long	£6.25 £5.21
45	WE307197700 Available to backorder	2004 Metric Fwd Rev Link Plate	£34.98 £29.15
46	WE08819800 In stock	Washer 516Id X 1Od Hd	£21.10 £17.58
47	6408 In stock	M8 Internally Serrated Shakeproof Washe	£0.48 £0.40
48	7746 In stock	Bolt M8 X 25mm	£0.48 £0.40
49	WE088845300 Available to backorder	9 Id X 22 Od X 2mm Thick Washer	£0.59 £0.49
50	WE06849100 In stock	2mm R Clip	£0.48 £0.40
51	WE189505300 Available to backorder	10mm Rose Joint Spacer	£1.99 £1.66
52	WE019480600 Available to backorder	M10 X 35 Bolt	£1.00 £0.83
53	WE328957000 Available to backorder	Handbrake Bearing Link Shaft Welded Assy	£29.69 £24.74
54	WE301122000 Available to backorder	A2050 Spring Tag	£5.70 £4.75
55	2148 In stock	Bolt M6 X 20mm (Vac) ( Af037868 )	£0.48 £0.40
56	WE541106700 Available to backorder	Diesel PTO Spring Retainer	£0.59 £0.49
57	WE541106500 Available to backorder	Spring Bracket	£0.59 £0.49
58	WE259405200 Available to backorder	Diff Spring A2050	£4.60 £3.83
59	WE541116600 Available to backorder	Deck Belt Tension Spring Bracket	£1.84 £1.53
