BC 241 HCL - Oleo-Mac Hedge Trimmer Transmission Diagram

Name: BC 241 HCL - Oleo-Mac Hedge Trimmer Transmission Diagram
SKU: bc_241_hcl_transmission-group
Price: 0.8 GBP
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

BC 241 HCL - Oleo-Mac Hedge Trimmer Transmission Diagram

Description

Oleo-Mac BC 241 HCL Parts Diagram

Be the first to review this product

0 product questions

	Part No.	Details
1	EF3891038R Available to backorder	Screw	£2.80 £2.33
2	EF61370052R Available to backorder	Clamp	£10.98 £9.15
3	EF61370259 Available to backorder	Handle	£41.06 £34.22
4	EF3893060R Available to backorder	Screw	£0.98 £0.82
5	EF61370043R Available to backorder	Lever	£2.76 £2.30
6	EF61370260 Available to backorder	Lever Group	£5.12 £4.27
7	EF61370044AR Available to backorder	Throttle Lever	£2.92 £2.43
9	EF4162154B Available to backorder	Knob	£8.74 £7.28
10	EF61290011R Available to backorder	Tube Ø24	£72.04 £60.03
11	EF61170075R Available to backorder	Drive Shaft	£29.33 £24.44
12	EF61370270A Available to backorder	Complete Handle	£28.06 £23.38
13	EF61370032AR Available to backorder	Cable	£5.64 £4.70
14	EF61370220AR Available to backorder	Throttle Cable	£8.74 £7.28
15	EF4160463AR Available to backorder	Harness	£15.06 £12.55
16	EF61370211R Available to backorder	Tool Kit	£12.48 £10.40
19	EF3914003R Available to backorder	Self-Locking Nut	£0.96 £0.80
